金属仓储笼
Product Features
1、Surface treatment:Zinc laquer or Zinc powder
Product specifications of wire mesh pallet box
| Model No. | Exterior Dimension | Interior High | Wire Guage | Grid Size | Loading Capacity | Loaded in 1x40'GP |
| LxWxH(mm) | mm | mm | mm | kg | sets | |
| ES08-01 | 1200x800x1000 | 850 | 5-12 | 60x103 | 800 | 480 |
| ES08-02 | 1000x1200x1450 | 1300 | 5-10 | 65x105 | 1000 | 280 |
| ES08-03 | 1200x1000x1200 | 1050 | 5-10 | 65x105 | 800 | 460 |
| ES08-04 | 1200x1000x1000 | 850 | 5-10 | 65x105 | 800 | 480 |
| ES08-05 | 1200x800x1000 | 850 | 5-10 | 65x105 | 800 | 480 |
| Material | Mild steel Q235 | |||||
| Application area | Warehouse, logistic, mass retail, agricultural, electronic equipment, etc. | |||||
| Finish | Zinc/hot-dip galvanized/powder coating | |||||
| Remark | Customized or OEM support | |||||
